想更換鏡頭玩看看, 上ebay
http://www.ebay.com/sch/i.html?_kw=m12+lens
如果行車記錄器的鏡頭換成這種規格, 可能會把基座扯下來吧?
如果真想玩鏡頭, AR0330的規格就很重要了!
AR0330規格參考,因為是原廠資料沒有中文,
看看有沒有網友要嘗試更換鏡頭試試~
================================
AR0330官網資料
Specifications
General
Part Status Production
Solution DV
Array
Res. 3.5MP
Optical Format 1/3 inch
Active Array 2304x1536
Imaging Area 5.07mm H x 3.38mm V
CRA (Chief Ray Angle) 0,21,25
Sensitivity
Pixel Size 2.2µm
Responsivity 1.9V/lux=sec (550nm)
Speed/Output
Frame Rate 60 fps
Chroma RGB
Shutter type ERS
Data Rate 196MPS
Master Clock 6-64MHz
Data Format RGB
Environmental
Supply Voltage 1.8v/2.8v
Power Consumption 450mw
Operating Temperature -30C - 70C
ROHS Compliance Yes
Package
Package CLCC, CSP, Die
Package Dimension 11.4 x11.4, 6.3 x 6.7
